4" coaxial cable all brass made in china high quality pim -155dbc

Ask Lasest Price
Model Number :	DIN.JW.114S
Delivery Time :	Based on Q'ty, usually 7-15 days
Payment Terms :	TT 30% deposit in advance and TT 70% balance before shipping
Brand Name :	OEM is available
Certification :	RoHS
Price :	Based on Q'ty
Supply Ability :	10000pcs/day or based on Q'ty

Add to Cart

Product Details
Company Profile

DIN 7/16 connector male plug solder type for 1-1/4" coaxial cable all brass made in china high quality pim -155dbc

Contact Us :

Name :	Carl Wu
Email :	wubo@joytak.com
Skype :	carl-wu1984
Mobile:	+86-137 7536 7513
Whatsapp:	+86-137 7536 7513

DIN 7/16 connector

DIN 7/16 connector male plug solder type for 1-1/4" coaxial cable all brass made in china high quality pim -155dbc

Product categories:

RF connectors and adaptors (4.3-10, 7/16 DIN, N type, F Type, PAL, BNC, TNC, RCA, SMA, SMB, MCX, MMCX etc)

Feeder Cables (Brand: Hansheng,Hengxing,Kingsignal etc, Type: 1/2", 1/2"SF, 7/8", RG59, RG6, RG174, LMR400 etc.)

IBS products (splitter,coupler, combiner, 3M tape, cable clamp, Ground copper bar, Grounding kits, electric cabinet, Heat Shrink Sleeve etc.)

Attenuators

Lightening Arrestors

RF Cable Assebmlies

Antennas (ZTE, MOBI etc.)

Center Pin ( inner conductor )

7/16 DIN male connector and DIN 7/16 female connector RF connector N male clamp type for 1/2 flex cable RF SMA connector flange type RF connector N male and N female RF QMA connector DIN 7/16 male and DIN 7/16 female for 1/2SF and 7/8 cable

Our Production Line ( CNC for connector body, inner conductor, PTFE dielectric),

Connector's packaing

Testing equipment for Connectors and jumpers (PIM tester, VSWR tester, RoHS tester, Salt spraying tester etc.)

factory producing and testing facilities for RF connector

Note: These characteristics are typical but may not apply to all connectors.

Mechanical

Durability	Mating cycles ≥500

Interface	IEC 60169-16;MIL-C-39012;CECC-22210
Characteristic Impedance	50ohm
RoHs (2002/95/EC) Compliant by exemption

Electrical

1	Characteristic Impedance	50ohm
2	Frequency Range	DC-3GHz
3	VSWR	(DC-3GHz)≤1.15
4	Dielectric withstanding voltage	≥2500RMS,50Hz,at sea level
5	Dielectric Resistance	≥5000MΩ
6	Contact Resistance	Center Contact ≤1mΩ ; Outer Contact ≤0.25 mΩ
7	Insert Loss	≤0.24dB(6GHz)
8	PIM ( @2-tonex20w)	≤ -155dBc@2×20W

Material and plating

	Description	Material	Plating
1	Body	Brass	Tri-alloy(CuZnSn) or Ni plated
2	Insulator	PTFE	–
3	Center conductor	Phosphor bronze	Ag
4	Gasket	Silicone rubber	-
5	Other	Brass	Ni

Environmental

1	Temperature Range	-40℃~+85℃
2	Watertightness	IP67
3	Rosh-compliance	Full ROHS compliance
4	Salt spraying test	96h

RF cable assembly SMA pigtail IPEX to N female RF cable assembly RF cable assembly SMA male for RG174 RF cable assembly 4.3-10 connector for 1/2" super flexible cable RF cable assembly DIN 7/16 male connector to DIN 7/16 female connector for 1/2 super flexible cable

About Us

We are a professional manufacturer for RF coaxial connector, RF coaxial adapters, RF coaxial cable assemblies in China. The products are used by China Mobile, China Telecom, HUAWEI, Amphenol etc.

Customers from India, Germany, France, USA, Italy, S.Africa, Australia etc. who has established long term cooperation with us because of premium quality products, effective service and reasonable price.

Also one-stop-service is provided to cusutomer with feeder cable, splitter, coupler and other IBS products.

Address	Xinfeng Economic Development Zone, Xinfeng Town, Dantu District
City	Zhenjiang
Province	Jiangsu
Post code	212100

It's nearby Nanjing, Changzhou, Wuxi and Suzhou. 2 and half hours to Shanghai by CRH.
